| Capacity kg(lb.)： | 1500 (3300) |
| Min. Fork Height mm(in.)： | 65 (2.6) |
| Max. Fork Height mm(in.)： | 5500 (216.5) |
| Fork Length mm(in.)： | 1000 (39.4) |
| Overall Forks Width mm(in.)： | 200-590 (7.4-2.7) |
| Individual Fork Width mm(in.)： | 100 (3.9) |
| Load Centre mm(in.)： | 600 (23.6) |
| Overall Dimensions mm(in.)： | 2507×940×2175 (98.7×37×85.6) |
| Extended Mast Height mm(in.)： | 5375 |
| Front Load Roller mm(in.)： | Tandem,φ78×70 (φ3×2.7) |
| Steering Wheel mm(in.)： | φ150×50 (φ6×2) |
| Driving Wheel mm(in.)： | φ250×80 (φ10×3.1) |
| Turning Radius mm(in.)： | 1605 (63.2) |
| Traveling Motor (W/V)： | 1200 |
| Traveling Speed(Loaded/Unloaded) (Km/h)： | 5.2/6.8 |
| Lifting Motor (W/V)： | 3000 |
| Lifting Speed(Loaded/Unloaded) (mm/s)： | 127/170 |
| Lowering Speed(Loaded/Unloaded) (mm/s)： | 127/170 |
| Battery (V/Ah)： | Traction Battery,24/240 |
| Charger (A/V)： | 30/24 |
| Battery Weight kg(lb.)： | 230 (506) |
| Net Weight kg(lb.)： | 1370 (3014) |
| Full Free Lifting Height mm(in.)： | 1717 (67.6) |
| Type： | Electric,Standing,with platform |
| Steering Handle： | O |
