| Capacity kg(lb.)： | 240 (528) |
| Max. Working Height mm(in.)： | 5500 (216.5) |
| Min. Platform Height mm(in.)： | 720 (28.3) |
| Max. Platform Height mm(in.)： | 3500 (137.7) |
| Platform Size mm(in.)： | Steel,1306×526 (51.4×20.7) |
| Overall Size mm(in.)： | 1455×780×1825 (57.3×30.7×71.9) |
| Stow Height(Guardrails Up/Down) mm(in.)： | 1825/845 (71.8/33.2) |
| Ground Clearance mm(in.)： | 40 (1.5) |
| Lift Speed-Raise/Lower(without load) (sec.)： | 23/25 |
| Raise/Lower Lift Speed(with load) (sec.)： | 27/27 |
| Wheels mm(in.)： | 4×φ200 (4×φ8),Aluminum Rubber |
| Lift Motor (V/W)： | DC,12/800, 0.75cc |
| Battery (V/Ah)： | 12/80 |
| Charger (A/V)： | DC,8/12 |
| Battery Weight kg(lb.)： | 21.5 (47.3) |
| Gross Weight kg(lb.)： | 362 (796) |
| Type： | Push |
