| Type： | Electric Three Wheel(AC) |
| Rated Capacity kg(lb.)： | 1800 (3960) |
| Load Center mm(in.)： | 500 (19.7) |
| Lift Height mm(in.)： | 3000 (118.1) |
| Free Lift Height mm(in.)： | 145 (5.7) |
| Fork Size mm(in.)： | 1070×100×40 (42.1×3.9×1.6) |
| Tilting Angle(Front/Rear)： | 6.5°/6.5° |
| Length to Fork Face mm(in.)： | 1965 (77.4) |
| Overall Length mm(in.)： | 3035 (119.5) |
| Overall Width mm(in.)： | 1060 (41.7) |
| Mast Height(Lowered/Raised) mm(in.)： | 2085/4045 (82.1/159.3) |
| Safeguard Height mm(in.)： | 2060 (81.1) |
| Min. Turning Radius mm(in.)： | 1580 (62.2) |
| Overhang mm(in.)： | 395 (15.6) |
| Wheel Distance(Front/Rear) mm(in.)： | 912/175 (35.9/6.9) |
| Ground Clearance mm(in.)： | 90 (3.5) |
| Wheelbase mm(in.)： | 1360 (35.5) |
| Fork Adjustment Range mm(in.)： | 200～1000 (7.9～96.4) |
| AST(pallet 800×1200)Lengthways mm(in.)： | 3370 (132.7) |
| AST(pallet 1000×1200)Crossways mm(in.)： | 3250 (128) |
| Traveling Speed(Loaded/Unloaded) (Km/h)： | 14/14 |
| Lifting Speed(Loaded/Unloaded) (mm/s)： | 280/480 (11/18.9) |
| Gradeability(Loaded/Unloaded) (%)： | 15/20 |
| Net Weight kg(lb.)： | with battery,3340 (7348) |
| Front Wheel mm(in.)： | 2×18×7-8 |
| Rear Wheel mm(in.)： | 2×15×4.5-8 |
| Driving Motor (Kw)： | 2×5.5,Manufacturer:ZF |
| Lifting Motor (Kw)： | 8.6 |
| Battery (Ah/V)： | 48/550 |
| Controller Type,Manufacturer： | MOSFET,SME |
| Working Pressure (Mpa)： | 14.5 |
