| Type： | Battery,Seat |
| Load Capacity kg(lb.)： | 3000 (6600) |
| Rated Traction Force (N)： | 820 |
| Wheelbase mm(in.)： | 1130 (44.5) |
| Services Weight(with battery) kg(lb.)： | 770 (1694) |
| Axle Load(Front/Rear) kg(lb.)： | 244/526 (536.8/1157.2) |
| Tyre(Front/Rear) mm(in.)： | φ267×76×165/φ330×114×203 (φ10.5×3×6.5/φ13×4.5×8), Solid Rubber |
| Wheel Number(Front/Rear,X=driven)： | 2/2X |
| Track Width(Front/Rear) mm(in.)： | 138/705 (5.4/27.8) |
| Height of Seat(stand-on platform) mm(in.)： | 750 (29.5) |
| Towing Bracket middle Height mm(in.)： | 240 (9.5) |
| Platform Height mm(in.)： | 660 (26) |
| Rear Overhang mm(in.)： | 360 (14.2) |
| Overall Length mm(in.)： | 1690 (66.5) |
| Overall Width mm(in.)： | 820 (32.3) |
| Ground Clearance(centre of wheelbase) mm(in.)： | 80 (3.1) |
| Turning Radius mm(in.)： | 1430 (56.3) |
| Drive Motor(60 minute rating) Kw(Hp)： | 2.5 (3.4) |
| Battery Voltage(rated capacity,5 h) (V/Ah)： | 24/300 |
| Battery Weight kg(lb.)： | (±5%)256 (560) |
| Type of Drive Control： | Electronic, MOSFET |
| Noise Level at Operator's Ear dB(A)： | 66 |
| Travel Speed(with/without load) Km/h(Mph)： | 6/7.2 (3.7/4.5) |
| Service Brake： | Mechanism drum |
